Ford Small Block Compatible 302 c.i. Engine and TKX Manual Transmission - 370 Horsepower - Standard Edition Builder Series - Polished Pulley Kit - Fuel Injected

Ford Small Block Compatible 302 c.i. Engine and TKX Manual Transmission - 370 Horsepower - Standard Edition Builder Series - Polished Pulley Kit - Fuel Injected

Description:Ā

  • Horsepower & Torque: 370 Horsepower / 350 ft. lbs. Torque
  • Compression Ratio: 9.5:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Cast Crank
  • Hypereutectic Pistons

Block:

  • BluePrint Engines High-Strength Cast Iron Block
  • Increased Deck Thickness and Strength Webbing
  • Priority Main Oiling
  • 4000" Bore
  • 4-Bolt Main
  • 1-Piece Rear Main Seal
  • Improved Water Jacket Design

Rotating Assembly:

  • Ford, Machined and Balanced by BluePrint Engines
  • 3.000" Stroke
  • OEM Type 5.090ā€ Connecting Rods
  • Hypereutectic Pistons
  • 50oz External Balance

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - HP9009
  • 60cc Chamber
  • 2.02" Intake / 1.60" Exhaust Valves
  • 190cc Intake / 60cc Exhaust Runners

Cam Specs:

  • Cam Type: Roller
  • .543 Intake / .554 Exhaust Lift
  • 218 Intake / 226 Exhaust Duration
  • @.050-112 Degree Lobe Separation

Ignition Timing:

  • 34 Degrees Total at 3500 RPM

Also Includes:

  • Holley Sniper 2 EFI System - BPP550-510-3XX
  • EFI Fuel Pump Kit - BPP5267
  • Intake Manifold
  • Water Pump
  • Spark Plugs and Wires
  • Valve Covers
  • Distributor
  • Harmonic Balancer
  • Painted Oil Pan
  • Thermostat and Thermostat Housing
  • Polished Front Accessory Drive - BPP302FDACPS4
    • Driver Side Standard Rotation Water Pump
    • Type II Power Steering Pump
    • Remote Power Steering Pump Reservoir
    • 140amp 1-wire Alternator
    • 7B10 Peanut Air Conditioning Compressor

Assembled with CompleteĀ TKX Transmission Package:

  • Mcleod Super Street Pro Single Disk Clutch
  • Hydraulic Throw Out Bearing
  • Aluminum Bell Housing
  • Flywheel
  • Engine Guard
  • Starter
    • First Gear Ratio:Ā 2.87:1
    • Second Gear Ratio:Ā 1.89:1
    • Third Gear Ratio:Ā 1.28:1
    • Fourth Gear Ratio:Ā 1.00:1
    • Fifth Gear Ratio:Ā 0.81:1

Notes:

  • Not for use in pollution-controlled vehicles
  • The front accessory drive on this engine fits many vehicles, however it is the customer responsibility to accurately measure and confirm fitment.Ā  Note this is a low-profile design, but things such as power steering hoses, alternator wiring, and additional fittings/fabrication may be required on some vehicles.
  • PACKAGE SHIPS ASSEMBLED AS PICTURED.Ā
  • IF THIS IS BEING ORDERED FOR A FACTORY FIVE VEHICLE,Ā STOPĀ AND CALL US ATĀ 1-800-483-4263 FOR PROPER FITMENT OR VISITĀ FACTORYFIVEENGINES.COM

*A bronze distributor gear is NOT recommended on this engine
